SME Model 12 MK2 Turntable

From: £10,474.00

What HFL Thinks

SME Model 12 MK2 Turntable – We love our vinyl at HFL and I don’t think there is any question that SME make some of the best turntables in the world today. Until you have experienced the legendary build quality of an SME turntable you really have no idea of the levels and the attention to detail SME go to when developing and building their turntables. They really are designed to last a life time whilst giving a very accurate and musical presentation of your beloved vinyl collection, in all honesty no one makes turntables like SME so please come in to HFL to experience an SME turntable for yourself.

Request a demonstration Product Enquiry
Categories: , , , Tags: ,

The MK2 Model 12 is designed and precision engineered for pure audio reproduction. The all-new highly advanced drive system provides much improved speed control, accuracy and stability. This best-selling and very capable precision turntable has evolved to deliver the perfect listening experience.

Tonearm choice can be upgraded to the superior SME Series IV or V.

Click here for more information

PRIMARY FEATURES

  • Natural, Open and Dynamic Sound
  • High Mass and Small Footprint
  • Close Tolerance Precision Bearing
  • Isolated Suspension
  • Precision Magnesium Tonearm
  • Highly Advanced New Drive System
  • Independent Mains Transformer
  • LEMO Low Power Cables
  • RCA Chassis Connectors
  • Crystal Cable Internal Wiring
  • Based on the award-winning Synergy
  • Three Colour Options

SPECIFICATION

The MK2 Model 12 is a precision turntable of high mass made to exacting engineering standards for high performance. The chassis and sub-chassis are CNC machined from premium grade aluminium billet. The sub-chassis is suspended on an advanced isolation system for primary resonance control and houses the main bearing, platter and tonearm. Four fully adjustable feet are mechanically de-coupled from the main chassis by isolators providing base resonance control.



The main spindle is 19mm (3/4″) precision machined from high chrome tool steel, ground, super finished and supported in a sealed housing with individually fitted sintered bronze bearings of generous proportions needed for precise bearing and platter rotation.



The platter is machined from aluminium alloy and weighs over 4.6kg (10lb). The platter is extensionally dampened and the top surface iso-damp is diamond-turned with a fine scroll for acoustic performance. This method of finishing upsets a myriad of tiny fibres which Interface with the underside of the vinyl record.



A substantial record clamp operating on the reflex principle ensures the largest possible platter contact even when appreciable record warp is present.
The Model 12 motor conforms to the highest standards of silent running and the turntable is driven by a custom made bi-phase AC synchronous motor controlled by a highly advanced speed control unit providing precise speed accuracy and stability.
The MK2 Model 12 comes equipped with an SME Model 309 tonearm and internal wiring by Crystal Cable as standard. Tonearm choice can be upgrade to the superior Series IV or V.



SPEED CONTROL

The turntable is driven by a custom made bi-phase AC synchronous motor. The Speed Control Unit uses a dedicated DSP engine to generate two independent pure mathematical sine waves which provide total control of frequency, phase relationship and amplitude. These in turn are matched (tuned) to the motor for accuracy to obtain the best possible performance.



The speed range is 33.33 and 45rpm with independent memory settings via a switched encoder. Fine pitch speed increments/decrements of +/-0.01% of the selected speed are made by a rotary control on the Speed Control Unit fascia. The SCU case is CNC machined from billet aluminium. A separate mains Power Unit keeps the transformer remote from the SCU and audio signal cables.



TONEARM OPTIONS

Series 309 tonearm

Series IV tonearm

Series V tonearm



CRYSTAL CABLE WIRING

The Model 12 is equipped with a premium grade signal cable from Crystal Cable which is installed inside the tonearm. Pure mono-crystal silver conductors in miniature format. Providing precious metal in its most pure version, lifting the musical performance to a higher level.

Available in 7 Versions –

  • Model 12A – With Model 309 Tonearm – £10,474
  • Model 12A Classic with M2-9R Tonearm – £10,474
  • Model 12A-IV with Series IV Tonearm – £11,821
  • Model 12A-V with Series V Tonearm – £13,843
  • Model 12A Twin with 2 x Model 309 Tonearms – £15,158
  • Model 12A Twin with 2 x Model M2-9R – £15,158
  • Model 12A Twin with Model 309 & M2-9R £15,158
  • Model 12A Diamond Series with Model 309 – £13,708

Weight & Dimensions

Turntable
Width: 370mm
Depth: 350mm
Height (top of tonearm): 178mm
Platter Diameter: 304mm
Spindle to Arm 215.35mm

Speed Control Unit
Width: 170mm
Depth: 305mm
Height: 68mm

Power Unit
Width: 190mm
Depth: 243mm
Height: 83mm

Platter: 305mm

Weight
Turntable: 21.26kg
Power Unit: 4.04kg
Speed Control Unit: 2.88kg
Shipping Weight: 33kg

Manuals & Download

MODEL-12 Mk2 Manual
